X-Ray Diffraction Facilty

PAN lytical XRD

Click here to Book Solt for Bruker XRD Facility




PANanalytical Empyrean
ACMS 101


How to book slots

XRD slots can only be booked online in three steps.
Click the link "Request Slots" and fill in the details as requested. You can select an empty slot upto 1 month in advance and only for week days. You can check the availability of slots using the module "Check Slot" or you can check "Booking status" to see all the slots which have already been taken.
Once you submit the request, an invoice will be generated. Please submit this invoice to Mr. G.P Bajpai (7933/7862) within 24 hours. If you do not submit within this time lime, your slot will get automatically cancelled and will be open for booking again.
Lab-in-charge will then accept your booking and you can check your status at "Booking status".
Please note that we will soon make this procedure paperless, but until then you will have to submit the paper invoice.
Note for MSE-PG students: MSE-PG students dont need to submit the invoice. Once you fill in all the details correctly, your requests will be automatically accpeted. If your request is pending for more than a day, then contact lab-in-charge.


User Charges




MSE

IITK Non-MSE

Academia Non IITK

Industry

Thin Film XRD

600

1200

2000

6000

Ambient polycrystalline XRD

300

600

1000

3000

SAXS and GISAXS

300

600

1000

3000

Texture and Residual stress*

600

1200

2000

6000

Reflectivity

300

600

1000

3000

Rocking curve

600

1200

2000

6000

High temperature**

4000

5000

8000

12000

Low temperature***

5000

6000

8000

12000
